Supported Block Transfer Messages B–23
User Text
String User Text String Read 3 261 0 ➀ ➀ ➀ ➀ ➁
User Text String Write 11 -32507 0 char 1/
char 0 char 3/
char2 char 5/
char4 char 7/
char 6 ➁
Product ID
Number Read Product ID Number Read 3 256 0 ➀ ➀ ➀ ➀ B-8
Clock Data Real Time Clock Data Read 3 2816 0
➀ ➀ ➀ ➀ ➁
Real Time Clock Data Write 7 -29952 0 sec./100th hour/min. date/day year/month ➁
Run Time
Accumulator Clear Run Time Accumulator 3 -29950 0 ➀ ➀ ➁
Run Time Accumulator Data
Read 3 2817 0
➀ ➀ ➀ ➀ ➁
Time Stamp Load Clock Info Reference
Stamp 3 -29950 Time Stamp
Number ➀ ➀ ➀ ➀ ➁
Reference Time Stamp Data
Read 3 2816 Time Stamp
Number ➀ ➀ ➀ ➀ ➁
Reference Time Stamp Data
Write 3 -29952 Time Stamp
Number
➀ ➀ ➀ ➀ ➁
Trend File All Info 3 4098 n x 4096 ➀ ➀ ➀ ➀ ➁ ➃
Maximum Trend Size Avail-
able 3 4097 0
➀ ➀ ➀ ➀ ➁ ➃
Number of Trends Available 3 4096 0 ➀ ➀ ➀ ➀ ➁ ➃
Run File Data 3 4100
➂ ➀ ➀ ➀ ➀ ➁ ➃
Setup Data Full 15 -28670 n x 4096 ➀ ➀ ➀ ➀ ➁ ➃
Trend Command 4 -28672 n x 4096 1 – 3 ➀ ➀ ➀ ➁ ➃
Trend Parameter Definition 3 4102 n x 4096
➀ ➀ ➀ ➀ ➁ ➃
Trend Status 4 4097 n x 4096 1 – 4 ➀ ➀ ➀ ➁ ➃
Trend Triggered Setup
Parameter 3 4103 n x 4096 ➀ ➀ ➀ ➀ ➁ ➃
Trigger Time 3 4099 n x 4096 ➀ ➀ ➀ ➀ ➁ ➃
Class Message
Word 0 Word 1 Word 2 Word 3 Word 4 Word 5 Word 6
Example
Message
Length Decimal
Value
Data Data Data Data Data
➀ This word is not used.
➁ Example not available in this manual. Refer to the 1336 FORCE PLC Communications Adapter User Manual, Publication 1336 FORCE -5.13.
➂
n x 4096 + offset (bits 0 – 11)
➃
Trending is a function of the 1336 FORCE drive with a PLC adapter board.
