P–2 Using This Manual
Contents of this Manual
Related Documentation
You can obtain documentation about Allen-Bradley products,
including PLC controllers, SLC controllers, Logix5550 controllers,
and drives, from your local Rockwell Automation office or
distributor. You can also access documents online at
http://www.ab.com/manuals
Application notes are available at
http://www.ab.com/drives/stddrives/faxback/faxback.htm
Terms and Abbreviations The following terms are specific to this product. For a complete
listing of automation terminology, refer to the Rockwell Automation
Industrial Automation Glossary, Publication Number AG-7.1.
Chapter Title Contents
Preface Using This Manual Descriptions of the audience, purpose, back-
ground, and scope of this manual.
1 Overview Features of the Remote I/O communications
module.
2 Configuring the Module Procedures for setting DIP switches.
3 Installing the Module Procedures for mounting, connecting cables, and
connecting power.
4 Creating Ladder Logic
Programs Information about addressing, information trans-
fer, and sample programs.
5 Using Block Transfer
Messages Information about messaging and sample pro-
grams.
6 Troubleshooting Information about troubleshooting the module.
A Specifications Environmental, electrical, and communication
specifications.
B Supported Block Transfer
Messages Information about block transfer messages.
Terms Definition
Controller A solid-state control system that has a user-programmable memory for
storage of instructions to implement specific functions such
as I/O control, logic, timing, counting, report generation, communica-
tion, arithmetic, and data file manipulation. A controller is also called a
“programmable logic controller” or “processor.”
Remote I/O I/O connected to a processor across a serial link. With a serial link,
remote I/O can be located long distances from the processor.
Remote I/O
Communications
Module This module connects a SCANport product to a Remote I/O link. There
are three types of Remote I/O communications modules: 1203-GD1
module, 1203-GK1 module, and 1336-GM1 board. The Remote I/O
module is also referred to as “adapter,” “module,” and communications
module.”
SCANport A standard peripheral communications interface for various
Allen-Bradley drives and power products.
SCANport
Peripheral A device that provides an interface between SCANport and a commu-
nications system such as Remote I/O. It is often referred to as an
adapter or communications module. For example, the Remote I/O
module is a SCANport peripheral.
SCANport
Product A device that uses the SCANport communications interface to commu-
nicate with one or more peripheral devices. For example, a motor drive
such as a 1336 PLUS is a SCANport product.
