Page 44

4–6
Creating Ladder Logic Programs
SCANport Product Settings
Logic Command bits
In our example, we are using a 1336 PLUS drive. The Logic
Command bits for it are:
The 1305 drives, 1336 PLUS II drives, and 1336 Spider drives use the
same Logic Command and Logic Status data. For other drives, refer
to their user manuals.
Logic Command Bits
Function
Description
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
X
Stop
➀
1=Stop, 0=No Operation
X
Start
1=Start, 0=No Operation
X
Jog
1=Jog, 0=No Operation
X
Clear Faults
1=Clear, 0=No Operation
X
X
Direction
00=No Operation, 01=Forward,
10=Reverse
X
Local
1=Local, 0=Multiplexed
X
MOP Increment
1=Increment MOP, 0=No Operation
X
X
Accel Rate Select
00=No Operation, 01=Rate 1, 10=Rate 2
X
X
Decel Rate Select
00=No Operation, 01=Rate 1, 10=Rate 2
X
X
X
Reference
Selection
000=No Operation
001=External Reference 1 (Par 5)
010=External Reference 2 (Par 6)
011=Preset 3
100=Preset 4
101=Preset 5
110=Preset 6
111=Preset 7
X
MOP Decrement
1=Decrement MOP, 0=No Operation
➀
Asserting a 1 will stop the product.
