Rockwell Automation 193-EDN E1Plus Overload Relays - DeviceNet Module User Manual
Page 67

Publication 193-UM006A-EN-P – October 2005
DeviceNet Information B-15
The following common services are implemented for the Control Supervisor
Object:
104
Get
Trip Log 2
WORD
Last trip condition. Bit definitions of the value are the same as
attribute 114.
105
GEt
Trip Log 3
WORD
Last trip condition. Bit definitions of the value are the same as
attribute 114.
106
Get
Trip Log 4
WORD
Last trip condition. Bit definitions of the value are the same as
attribute 114.
107
Get
Device Status
WORD
Bit 0=Trip
Bit 1=Warning
Bit 2=OutputA
Bit 3=Input 1
Bit 4=Input 2
BIt 5=Motor Current
108
Get/Set
Trip Enable
WORD
Bit 0=Not Used
Bit 1=Not Used
Bit 2=Jam
Bit 3=Not Used
Bit 4=Not Used
BIt 5=Not Used
Bit 6=Not Used
Bit 7=Not Used
109
Get/Set
Warning Enable WORD
Bit 0=Overload
Bit 1=Not Used
Bit 2=Jam
Bit 3=Underload
Bit 4=Not Used
BIt 5=Comm Fault
Bit 6=Comm Idle
Bit 7=Not Used
110
Get/Set
Reset Mode
BOOL
0=Manual
1=Automatic
111
Get/Set
IN1 Assignment USINT
0=Normal
1=Trip Rest
2=OL Contact
112
Get/Set
IN2 Assignment USINT
0=Normal
1=Trip Reset
2=OL Contact
Table B.35 Control Supervisor Object Instance Attributes
Attribute
ID
Access Rule
Name
Data Type
Value
Table B.36 Control Supervisor Object Common Services
Service
Code
Implemented for:
Service Name
Class
Instance
0x0E
No
Yes
Get_Attribute_Single
0x10
No
Yes
Set_Attribute_Single
