Reset/lock group – Rockwell Automation 193-EDN E1Plus Overload Relays - DeviceNet Module User Manual
Page 33

Publication 193-UM006A-EN-P – October 2005
Device Parameters 4-9
Reset/Lock Group
Trip Reset
Parameter No. 14
This parameter provides the user with the
capability of resetting a trip over the DeviceNet
network. After a trip is reset, the parameter
automatically returns to a “Ready” state.
Access Rule
Get/Set
Data Type
BOOL
Group
Reset/Lock
Units
—
Min. Value
0 = Ready
Max. Value
1 = Reset Trip
Default Value
0
Program Lock
Parameter No. 24
This parameter prohibits the device parameters
from being altered when set to “Locked”. It must
be set to “Unlocked” to allow parameter
modification.
Access Rule
Get/Set
Data Type
BOOL
Group
Reset/Lock
Units
—
Min. Value
0 = Unlocked
Max. Value
1 = Locked
Default Value
0
Set To Defaults
Parameter No. 25
This parameter allows the user to reset the
parameter settings to the factory default values.
After parameter values have been reset to the
factory default settings, the parameter
automatically returns to a “Ready” state.
Access Rule
Get/Set
Data Type
BOOL
Group
Reset/Lock
Units
—
Min. Value
0 = Ready
Max. Value
1 = Reset Defaults
Default Value
0
