B-12 DeviceNet Information
Parameter Object —CLASS CODE 0x000F
The following class attributes are supported for the Parameter Object:
The following instance attributes are implemented for all parameter attributes:
Table B.29 Parameter Object Class Attributes
Attribute ID
Access Rule
Name
Data Type
Value
1
Get
Revision
UINT
1
2
Get
Max Instance
UINT
38
8
Get
Parameter Class Descriptor
WORD
0x03
9
Get
Configuration Assembly Instance
UINT
0
10
Get
Native Language
UINT
1= English
Table B.30 Parameter Object Instance Attributes
Attribute ID
Access Rule
Name
Data Type
Value
1
Get/Set
Value
Specified in Descriptor
2
Get
Link Path Size
USINT
08
3
Get
Link Path
Array of
BYTE
EPATH
Path to specified object attribute.
4
Get
Descriptor
WORD
Parameter Dependent
5
Get
Data Type
EPATH
Parameter Dependent
6
Get
Data Size
USINT
Parameter Dependent
7
Get
Parameter Name String
SHORT_STRING
Parameter Dependent
8
Get
Units String
SHORT_STRING
Parameter Dependent
9
Get
Help String
SHORT_STRING
Parameter Dependent
10
Get
Minimum Value
Specified in Descriptor
Parameter Dependent
11
Get
Maximum Value
Specified in Descriptor
Parameter Dependent
12
Get
Default Value
Specified in Descriptor
Parameter Dependent
13
Get
Scaling Multiplier
UINT
01
14
Get
Scaling Divisor
UINT
01
15
Get
Scaling Base
UINT
01
16
Get
Scaling Offset
INT
00
17
Get Multiplier
Link
UINT
0
18
Get
Divisor Link
UINT
0
19
Get
Base Link
UINT
0
20 Get
Offset
Link
UINT
0
21
Get
Decimal Precision
USINT
Parameter Dependent
