Rockwell Automation 193-EDN E1Plus Overload Relays - DeviceNet Module User Manual
Page 66

Publication 193-UM006A-EN-P – October 2005
B-14 DeviceNet Information
The following common services are implemented for the Parameter Group
Object:
Control Supervisor Object — CLASS CODE 0x0029
No class attributes are supported for the Control Supervisor Object. A single
instance (instance 1) of the Control Supervisor Object is supported. The
following instance attributes are supported.
Table B.34 Parameter Group Object Common Services
Service
Code
Implemented for:
Service Name
Class
Instance
0x0E
Yes
Yes
Get_Attribute_Single
Table B.35 Control Supervisor Object Instance Attributes
Attribute
ID
Access Rule
Name
Data Type
Value
10
Get
Tripped
BOOL
0=No Fault present
1= Fault Latched
11
Get
Warning
BOOL
0=No Warning Present
1=Warning present (not latched)
12
Get/Set
Fault Reset
BOOL
1…>1=Trip Reset; otherwise no action
13
Get
Trip Code
UINT
ODVA TRip Code—In trip state indicates cause of trip; if not tripped,
indicates cause of last trip.
14
Get
Warning Code
UINT
ODVA Warning Code—In warning state indicates cause of warning;
if no warning, indicates cause of last warning.
100
Get
Trip Status
WORD
Bit 0=Overload
Bit 1=Phase Loss
Bit 2=Jam
Bit 3=Not Used
Bit 4=Not Used
BIt 5=Not Used
Bit 6=Not Used
Bit 7=Not Used
101
Get
Warning Status
WORD
Bit 0=Overload
Bit 1=Not Used
Bit 2=Jam
Bit 3=Underload
Bit 4=Not Used
BIt 5=Comm Fault
Bit 6=Comm Idle
Bit 7=EEPROM
102
Get
Trip Lob 0
WORD
Last trip condition. Bit definitions of the value are the same as
attribute 114.
103
Get
Trip Log 1
WORD
Last trip condition. Bit definitions of the value are the same as
attribute 114.
