Rockwell Automation 193-EDN E1Plus Overload Relays - DeviceNet Module User Manual
Page 57

Publication 193-UM006A-EN-P – October 2005
DeviceNet Information B-5
Input Assemblies
Table B.13 Instance 50 — Basic Overload Input Assembly from ODVA Overload
Profile
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Tripped
Table B.14 Instance 51 —Extended Overload Input Assembly from ODVA Overload
Profile
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Warning
Tripped
Table B.15 Instance 100 — Parameter Based Input Assembly
Word
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
0
Value of the parameter pointed to by parameter #30 (low byte)
1
Value of the parameter pointed to by parameter #30 (high byte)
1
2
Value of the parameter pointed to by parameter #31 (low byte)
3
Value of the parameter pointed to by parameter #31 (high byte)
2
4
Value of the parameter pointed to by parameter #32 (low byte)
5
Value of the parameter pointed to by parameter #32 (high byte)
3
6
Value of the parameter pointed to by parameter #33 (low byte)
7
Value of the parameter pointed to by parameter #33 (high byte)
Table B.16 Instance 106 —Motor Starter Input Assembly
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Motor
Current
Input 2
Input 1
Out A Stat Warning
Tripped
Table B.17 Instance 110 —Extended Motor Starter Input Assembly
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
0
Motor
Current
Input 2
Input 1
Out A Stat Warning
Tripped
1
Unused
2
Average %FLA
3
4
%Therm Utilized
5
