Publication 193-UM006A-EN-P – October 2005
Device Parameters 4-13
OutA DN IdlState Parameter No. 38
This parameter, in conjunction with
parameter 39, defines how Output A will
respond when the DeviceNet network is idle.
When set to “1”, Output A will hold the state
prior to trip occurrence. When set to “0”,
Output A will open or close as determined by
the setting in Parameter 39. The DN Flt
parameters supersede the DN Idl
parameters. Access Rule Get/Set
Data Type BOOL
Group I/O Setup
Units —
Min. Value 0 = Go To IdlValue (#39)
Max. Value 1 = Hold Last State
Default Value 0
OutA DN IdlValue Parameter No. 39
This parameter determines the state that Output
A assumes when the network is idle and
parameter 38 is set to “0”. Access Rule Get/Set
Data Type BOOL
Group I/O Setup
Units —
Min. Value 0 = Open
Max. Value 1 = Closed
Default Value 0
IN1 Assignment Parameter No. 40
This parameter allows the user to assign a
specific function to the discrete IN1 input. Access Rule Get/Set
Data Type USINT
Group I/O Setup
Units —
Min. Value
Max. Value
0 = Normal
1 = Trip reset
2 = OL Contact
Default Value 0
IN2 Assignment Parameter No. 41
This parameter allows the user to assign a
specific function to the discrete IN2 inputs. Access Rule Get/Set
Data Type USINT
Group I/O Setup
Units —
Min. Value
Max Value
0 = Normal
1 = Trip Reset
2 = OL Contact
Default Value 0
