Devicenet information, Appendix, Electronic data sheets – Rockwell Automation 193-EDN E1Plus Overload Relays - DeviceNet Module User Manual
Page 53: Devicenet objects

1
Publication 193-UM006A-EN-P – October 2005
Appendix
B
DeviceNet Information
Electronic Data Sheets
Electronic Data Sheet (EDS) files are specially formatted ASCII files that
provide all of the information necessary for a configuration tool (e.g.,
RSNetWorx for DeviceNet) to access and alter the parameters of a device. The
EDS file contains all the parameter information of a device: number of
parameters, groupings, parameter name, min, max, and default values, units,
data format and scaling. The EDS file for the E1 Plus DeviceNet Module is
available from the Internet at www.ab.com/networks/eds/index/html. It can
also be built automatically by some configuration tools since all of the
information necessary for an EDS file may be extracted from the E1 Plus
DeviceNet Module.
DeviceNet Objects
The following object classes are supported.
Table B.1 DeviceNet object Classes
Class
Object
0x0001
Identity
0x0002
Message Router
0x0003
DeviceNet
0x0004
Assembly
0x0005
Connection
0x0008
Discrete Input Point
0x0009
Discrete Output Point
0x000F
Parameter
0x0010
Parameter Group
0x0029
Control Supervisor
0x002B
Acknowledge Handler
0x002C
Overload
0x00B4
DN Interface
