Rockwell Automation 150 SMC Quick Start Manual User Manual
Page 13
Rockwell Automation Publication 150-QS003D-EN-P - November 2013
11
Installation Chapter 2
Figure 5 - Dimensions of Cat. No. 150-SC Controller with Lugs, Bypass Kit,
and MOV options
26.84
(681.8)
1.44 (36.5)
8.23
(209.2)
6.08
(154.4)
3.08
(78.2)
27.23
(691.6)
23.25
(590.6)
3.15
(80)
0.35
(8.8)
1.02
(26)
2.14
(54.2)
1.44
(36.5)
0.53
(13.4)
26.17
(664.6)
1.70
(43.2)
Catalog Number Approximate Shipping Weight
150-SC1…
47.6 kg
105 lb
150-SC2…
150-SC3…
