8 Rockwell Automation Publication 150-QS003D-EN-P - November 2013
Chapter 2 Installation
Dimensions
Cat. No. 150-SB… Controllers
Figure 2 - Dimensions of Cat. No. 150-SB Controller without Terminal Covers
NOTE:
Dimensions are in inches (millimeters). All dimensions are
approximate and are not intended for manufacturing purposes.
Consult your local Rockwell Automation sales office or
Allen-Bradley distributor for complete dimension drawings.
0.19
(4.8)
1.41
(35.8)
7.25
(184.2)
6.79
(172.5)
10.21
(259.2)
7.65
(194.4)
6.69
(170.0)
2.51
(63.7)
2.51
(63.7)
Four Quantity
Ø 0.296
(7.51)
14.63
(371.6)
6.25
(158.8)
0.30
(7.5)
1.07
(27.1)
2.76
(70.0)
13.39
(340.0)
15.62
(396.6)
13.95
(354.4)
See detail A
Detail A
#8-32 UNC 2B
0.79
(20)
0.49
(12.5)
0.41 dia
(10.5)
1.25
(31.8)
1.54
(39.1)
Catalog Number Approximate Shipping Weight
150-SB1…
15.7 kg
34.6 lb
150-SB2…
150-SB3…
150-SB4…
