AutoMax DCSNet/RE RIO Module Page 69
Publication number 56AMXN-UM002A-EN-P November 2002
Specifications
The 56AMXN/B is a standard ControlLogix module with the following
specifications:
Parameter Specification
Module Location ControlLogix chassis
Function ControlLogix AutoMax DCS and Remote I/O
module
Description Processor: 100MHz IDT MIPS
FLASH memory: 1Mbyte (512Kx16)
Local RAM: 1Mbyte (256Kx32) 50Mhz
synchronous SRAM
Shared RAM: 512Kbyte (128Kx32) 20ns
asynchronous SRAM
Maximum Backplane
Current Load 650mA @ +5.1V dc and 75mA @ 24 V dc
from I/O chassis backplane
Power dissipation 5W maximum
Environmental
Conditions:
Operational
Temperature 0-60°C (32-140°F)
Storage Temperature –40 to 85°C (–40 to 185°F)
Relative Humidity 5-95% without condensation
Shock Unpackaged 30g operational
50g non-operational
Vibration Unpackaged 2g from 10-150Hz
Marked for all applicable
directives Agency Certification
(when product or
packaging is marked)
Listed Industrial Control
Equipment
Installation Manual Publication 56AMXN-QS001A-EN-P August
2001
