InputDropMap Value Description
1 to 55 Drop data from drops, registers 0 to 31
56 Unused
Any other Invalid
OutputDropMap Value Description
1 to 55 Drop data to remote drops, registers 32 to 63
56 Unused
Any other Invalid
DCS Slave
InputDropMap Value Description
0 56AMXN Status/diagnostic registers
1 to 55 Drop data, registers 32 to 63, from master
-1 to –55 Drop data, slave to master, registers 0 to 31,
from monitored drops
56 Unused
Any other Invalid
OutputDropMap Value Description
1 to 55 Drop data, registers 0 to 31, from 56AMXN to
master
56 Unused
Any other Invalid
Duplicate entries in the InputDropMap or OutputDropMap areas are
invalid. The only exception is that there can be multiple blocks marked
as unused (56).
If the configuration tag contains invalid data, the connections to the
56AMXN do not open. The ControlLogix periodically retries the
connections so if you correct the invalid configuration data, the
connections will eventually open.
However, if you change the contents of a valid configuration tag in the
ControlLogix, you must break and remake the connections to the
56AMXN to cause the 56AMXN to use the modified configuration data.
