6/8 smooth-star doors – Therma-Tru COMP 5 Smooth-Star Door Panel Dimensions - Book Size User Manual

Page 9

background image

Smooth-Star
Door Panel
Dimensions

Comp 5

2014 (BOOK SIZE)

5.9

6/8 Smooth-Star Doors

A

B

C

D

4-17/32”

7-3/16”

4-15/16”

25”

21-13/16”

9-9/16”

79-1/4”

A

B

23-7/8”

C

9-1/8”

4-7/8”

79-1/4”

3-1/32”

9-3/32”

4-17/32”

25”

21-13/16”

9-9/16”

Size

A

C

2/6N

30”

4-1/2” 8-13/16” 3-13/32”

*2/6

30”

3-7/16”

9-1/8”

4-7/8”

2/8

32”

4-7/16”

9-1/8”

4-7/8”

2/10

34”

5-7/16”

9-1/8”

4-7/8”

3/0

36”

6-7/16”

9-1/8”

4-7/8”

*Impact slab not available.

Size

A

B

C

2/8

32”

4-1/16” 4-7/16”

2/10

34”

5-1/16” 5-7/16”

3/0

36”

6-1/16” 6-7/16”

6 Panel

(Slab-SS060, SS060N)

(Impact-SS060H, SS060NH)

4 Lite Scallop 4 Panel

(335, 2206)

(Slab-SS060)

B

D

E

21-1/32”

23-1/8”

23-1/8”

23-1/8”

23-1/8”

3-13/32”

23-1/8”

E

Daylight Opening: 5-1/8" x 21-1/8"

(98 sq.in.)
