Smooth-Star
Door Panel
Dimensions
Comp 5 2014 (BOOK SIZE) 5.15
6/8 Smooth-Star Doors
12-13/16”
43-7/8”
8-1/2”
4-3/4”
1-9/16”
66”
79-1/4”
11-1/16”
24-1/8” B
9”
7-1/2”
5-9/16”
9-7/8”
A
15”
39-1/2”
Size A B
2/8 32” 3-15/16”
2/10 34” 4-15/16”
3/0 36” 5-15/16”
Center Arch 7 Panel
(0842)
(Slab-SS300)
Daylight Opening: 6-15/16" x 40-15/16"
(292 sq.in.)
A
B
39-1/2”
9”
15”
7-1/2”
5-9/16”
11-1/16”
24-1/8”
12-13/16”
43”
8-1/2”
4-3/4”
2”
66”
79-1/4”
Size A B
2/8 32” 3-15/16”
2/10 34” 4-15/16”
3/0 36” 5-15/16”
8 Panel
(Slab - SS300)
(Impact - SS300H)
