Smooth-Star
Door Panel
Dimensions
5.10
2014 (BOOK SIZE)
Comp 5
6/8 Smooth-Star Doors
A
B
23-27/32”
C
9-1/8”
4-7/8”
4-1/8”
7-7/8”
4-21/32”
25”
21-13/16”
9-9/16”
79-1/4”
A
B
9-7/8”
D
C
E
F
4-3/16”
7-7/8”
4-19/32”
25”
6-3/16”
21-13/16”
9-19/32”
79-1/4”
Size
A
B
C
2/8
32”
4-1/16” 4-7/16”
2/10
34”
5-1/16” 5-7/16”
3/0
36”
6-1/16” 6-7/16”
Size
A
B
C
D
E
F
2/6N
30”
3-31/32” 4-1/2”
2-11/32”
2/6
30”
3-1/16” 3-7/16”
4-1/8”
2/8
32”
4-1/16” 4-7/16”
4-1/8”
2/10
34”
5-1/16” 5-7/16”'
4-1/8”
3/0
36”
6-1/16” 6-7/16”
4-1/8”
2 Lite 4 Panel
(296, 996, 0806)
(Slab-SS060)
4 Lite 4 Panel
(444)
(Slab-SS060)
23-1/8”
23-1/8”
3-3/8”
8-13/16”
9-1/8”
9-1/8”
9-1/8”
9-1/8”
4-7/8”
4-7/8”
4-7/8”
4-7/8”
Daylight Opening: 21-1/8" x 5"
(93 sq.in.)
A
B
9 15/16"
D
4 5/32"
7 15/16"
4 19/32"
25"
21 13/16"
9 9/16"
79 1/4"
2 Lite 4 Panel
(Glass - 296, 996, 0806)
(Slab - SS060)
C
E
F
Size
A
B
C
D
E
F
2/6N* 30" 3-31/32" 4-1/2" 2-11/32" 8-13/16" 3-3/8"
2/6
30"
3-1/16" 3-13/32" 4-1/8"
9-1/8" 4-7/8"
2/8
32"
4-1/16" 4-13/32" 4-1/8"
9-1/8" 4-7/8"
2/10
34"
5-1/16" 5-13/32" 4-1/8"
9-1/8" 4-7/8"
3/0
36"
6-1/16" 6-13/32" 4-1/8"
9-1/8" 4-7/8"
*Impact slab not available.
Daylight Opening: 6-15/16" x 4-15/16" (per lite)
(Total 68 sq.in.)
