Smooth-Star
Door Panel
Dimensions

Comp 5

2014 (BOOK SIZE)

5.27

8/0 Smooth-Star Doors

B

C

E

D

95-1/4”

H

A

Size

A

C

E

*2/6

3-15/16” 22-1/8” 82-1/8” 5-1/8”

*2/6 Impact

30”

30”

32”

32”

34”

34”

36”

36”

4-1/16” 21-7/8” 81-7/8” 5-1/4”

2/8

3-15/16” 24-1/8” 82-1/8” 5-1/8”

2/8 Impact

4-1/16” 23-7/8” 81-7/8” 5-1/4”

2/10

4-15/16” 24-1/8” 82-1/8” 5-1/8”

2/10 Impact

5-1/16” 23-7/8” 81-7/8” 5-1/4”

3/0

5-15/16” 24-1/8” 82-1/8” 5-1/8”

3/0 Impact

6-1/16” 23-7/8” 81-7/8” 5-1/4”

*Impact slab not available.

8’ Full Lite w/ Stile Lines

(808, 818, 828, 2280, 808N, 818N, 828N, 2080)

(Impact - 808H, 808NH, 828H, 818H,

818NH, 828NH)

(Slab - S8060)

(Impact - S8060H)

F

G

B

D

F

G

21”

21”

23-1/8”

23-1/8”

23-1/8”

23-1/8”

23-1/8”

23-1/8”

4-1/2”

4-1/2”

4-7/16”

4-7/16”

5-7/16”

5-7/16”

6-7/16”

6-7/16”

H

8”

8-1/8”

8”

8-1/8”

8”

8-1/8”

8”

8-1/8”

Note:

For Optional Grille Locations,

See Arch 1.

Daylight Opening: 18-15/16" x 78-15/16"

(2080 for 1" glass) (1495 sq.in.)

Daylight Opening: 19-1/8" x 79-1/8"

(2080 for 1/2" glass) (1513 sq.in.)

Daylight Opening: 20-15/16" x 78-15/16"

(2280 for 1" glass) (1653 sq.in.)

Daylight Opening: 21-1/8" x 79-1/8"

(2280 for 1/2" glass) (1672 sq.in.)

A

95 1/4"

5 3/32"

7 15/16"

4 9/16"

39 1/2"

23 3/4"

8 13/32"

B

D

F

8' 2 Lite 4 Panel

(Glass - 296, 0806)

(Slab - S8060)

9 15/16"

E

C

Size A

B

C

D

E

F

2/6 30" 3-15/16" 8-13/16" 2-9/32" 21"

4-1/2"

2/8 32" 4-1/16" 9-1/8" 4-1/16" 23-1/8" 4-7/16"

2/10 34" 5-1/16" 9-1/8" 4-1/16" 23-1/8" 5-7/16"

3/0 36" 6-1/16" 9-1/8" 4-1/16" 23-1/8" 6-7/16"

Daylight Opening: 6-15/16" x 4-15/16" (per lite)

(Total 68 sq.in.)
