Therma-Tru COMP 5 Smooth-Star Door Panel Dimensions - Book Size - Manual (Page 32)

Smooth-Star
Door Panel
Dimensions
5.32 2014 (BOOK SIZE) Comp 5
8/0 Smooth-Star Doors
A
B
4-17/32”
22-11/32”
5-7/16”
16-3/32”
5-11/32”
60”
8-3/8”
A
B
23-3/32”
16-27/32”
22-11/32”
4-17/32”
4-11/16”
95-1/4”
5-11/32”
60”
8-3/8”
8-29/32”
8-29/32”
95-1/4”
Size A B
2/8 32” 4-27/32”
2/10 34” 5-27/32”
3/0 36” 6-27/32”
8’ 2 Panel Craftsman
(Slab - SS8203, SH8203)
(Impact - SS8203H)
8’ Craftsman Lite 2 Panel - 1 Lite
(2115)
(Slab - SS8203)
Size A
2/8 32” 4-27/32”
2/10 34” 5-27/32”
3/0 36” 6-27/32”
4-29/64”
5-29/64”
6-29/64”
B C
C
Daylight Opening: 20-3/32" x 13-27/32"
(278 sq.in.)
