Smooth-Star
Door Panel
Dimensions
Comp 5
2014 (BOOK SIZE)
5.5
6/8 Smooth-Star Doors
A
B
C
G
F
E
D
*Impact slab not available.
Size
A
B
C
D 6/8
D 6/6
E
*2/0
24”
4-1/8”
15-3/4”
9-11/32” 6-13/16” 65-3/4”
*2/4
28”
5-1/16” 17-7/8”
9-7/32”
6-11/16” 65-7/8”
2/6
30”
4-1/16” 21-7/8”
9-7/32”
6-11/16” 65-7/8”
2/8
32”
5-1/16” 21-7/8”
9-7/32”
6-11/16” 65-7/8”
2/10
34”
5-1/16” 23-7/8”
9-7/32”
6-11/16” 65-7/8”
3/0
36”
6-1/16” 23-7/8”
9-7/32”
6-11/16” 65-7/8”
Full Lite Flush
(Impact - 140H, 141H, 1464H)
(108N, 118N, 128N, 1664, 2064, 2264)
(108, 118, 128, 916, 2264)
(Slab-SS010)
(Impact-SS010H)
Daylight Opening: 20-15/16" x 62-15/16"
(2264) (1317 sq.in.)
Note:
For Optional Grille Locations,
See Arch 1.
Height
F
G
*6/6
76-23/32" 4-5/32"
6/8
79-1/4"
4-5/32"
*7/0
83-1/4"
7-1/32"
Daylight Opening: 18-29/32" x 62-29/32"
(2064) (1189 sq.in.)
B
C
4-5/32"
37-29/32"
A
79-1/4"
Half Lite Flush
(Glass - 2236, 104, 137) (2036, 104N)
(Impact - 104H)
(Slab - SS010)
(Impact - SS010H)
Size
A
B
C
2/6
30" 4-1/16" 21-7/8"
2/8
32" 4-1/16" 23-29/32"
2/10 34" 5-1/16" 23-29/32"
3/0
36" 6-1/16" 23-29/32"
Daylight Opening: 19-1/8" x 35-1/8"
(2036) (672 sq.in.)
Daylight Opening: 20-29/32" x 34-29/32"
(2236) (729 sq.in.)
Note:
For Optional Grille Locations,
See Arch 1.
