Therma-Tru COMP 5 Smooth-Star Door Panel Dimensions - Book Size - Manual (Page 26)

Smooth-Star
Door Panel
Dimensions
5.26 2014 (BOOK SIZE) Comp 5
8/0 Smooth-Star Doors
A
B C
D 5-7/16 ”
5 ”
39-1/2 ”
95-1/4”
6 ”
23-3/4”
8-3/8”
7-3/16”
95-1/4”
8-13/32”
23-3/4”
48-3/4”
6”
23-1/8”
A
B
Size A B C
*2/6 30” 4-1/2” 8-13/16” 3-3/8”
2/8 32” 4-7/16” 9-1/8” 4-7/8”
2/10 34” 5-7/16” 9-1/8” 4-7/8”
3/0 36” 6-7/16” 9-1/8” 4-7/8”
Size A B
2/8 32” 4-7/16”
2/10 34” 5-7/16”
3/0 36” 6-7/16”
*Impact slab not available.
8’ 6 Panel
(Slab - S8060)
(Impact - S8060H)
8’ 2 Panel Soft Arch
(Slab - S8002)
(Impact - S8002H)
E
E
21”
23-1/8”
23-1/8”
23-1/8”
8-11/32”
D
