SDC 482A4RU ROUND PUSH PLATE SWITCH User Manual
Push to open
INSTALLATION INSTRUCTIONS
482A4RU ROUND PUSH PLATE SWITCH,
PUSH TO OPEN – 4-1/2” SPDT
P:\INSTALLATION INST\WIKK\INST-482A4RU.vsd REV -
01-13 Page 1
801 Avenida Acaso, Camarillo, Ca. 93012 • (805) 494-0622 •
www.sdcsecurity.com • E-mail: [email protected]
Any suggestions or comments to this instruction or
product are welcome. Please contact us through
our website or email [email protected]
19/32” [15]
N/
C
N/
O
CO
M
7/8” [22]
MIN STD
SWITCH
Specifications
Physical Size: 4-1/2" Dia x 1-15/32"D
Switch mounts to a Single Gang (2"x4") or Double Gang (4"x4")
electrical box
Contact Type: SPDT
Contact Rating: 2 Amp @48VDC
15 Amp @125/250VAC
4-1/2” [114]
PUSH
TO OPEN
