Instruction sheet, Prs.4tec – Prescolite SLOPED CEILING ADAPTORS User Manual
Page 5
www.prescolite.com
• Prescolite
TollFree
Technical
Support
1.888.PRS.4TEC
•
Hours:
8am
- 5pm
ET
701 Millennium Boulevard • Greenville, SC 29607
With representatives offices in principal cities throughout North America.
Copyright 2010, 02/10 revision, All Rights Reserved - Printed in U.S.A.
Part No. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 01863200
Instruction
Sheet
Flangeless for wet
ceiling installation
Max. ceiling angle: 35º
(taken from horizontal)
Dimension dependent
upon size of adator
and angle of slope
Stanard
fixture trim
Plaster flange on
stanard fixture housing
(requires field modifica-
tion to attach adaptor)
2
1
1
1
/
2
”
1
/
2
” flange for
dry ceiling
installation
(clearance hole)
SLOPED CEILING ADAPTOR
FOR RECESSED FIXTURES
