Omnitron Systems Technology iConverter 2FXM User Manual User Manual
Page 41
PI
Membership Entry - iConverter 2FXM
iConverter, Serial Agent
Identifier -
Chassis Number = 1 Slot Number = 1 Model Number = 8959-0
VLAN Table Membership Entry 1
------------------------------
+1: VLAN ID
100
+2: Port 1 Membership
Yes
3: Port 2 Membership
No
4: BP A Port Membership
No
5: BP B Port Membership
No
6: Mngmnt Port Membership
No
*7: Submit Entry As Defined
Enter Choice, Previous Screen(0), (H)elp, E(x)it >
SA
Membership Entry - iConverter 2FXM iConverter, Serial Agent
Identifier -
Chassis Number = 1 Slot Number = 1 Model Number = 8959-0
VLAN Table Membership Entry 1
------------------------------
+1: VLAN ID
100
+2: Port 1 Membership
Yes
3: Port 2 Membership
No
4: Mngmnt Port Membership
No
*5: Submit Entry As Defined
Enter Choice, Previous Screen(0), (H)elp, E(x)it >
Once all the VLAN IDs have been assigned, select option 7 or 5 to save the entries.
PI
VLAN Membership - iConverter 2FXM
iConverter, Serial Agent
Identifier -
Chassis Number = 1 Slot Number = 1 Model Number = 8959-0
VLAN ID (VID)
Port 1
Port 2
BP A
BP B
Mngmnt
1: 100
Yes
No
No
No
No
Add new entry (a), Delete entry (d), Edit entry (e), Clear table (c)
Enter Choice, Previous Screen(0), (H)elp, E(x)it >
The VLAN membership entries are saved from the Port configuration screen, option 4.
Page 41
