Tagged VLAN is accessed by selecting option 4 from the Port configuration screen. The Tag VLAN
Control screen will be displayed.
PI
Tag VLAN Control - iConverter 2FXM iConverter, Serial Agent
Identifier -
Chassis Number = 1 Slot Number = 1 Model Number = 8959-0
Port 1 1: Port Priority (PRI) 0 BP B 16: Port Priority (PRI) 0
2: PVID (Port VLAN ID 2 17: PVID (Port VLAN ID) 2
3: Tagged Packets Use PVID 18: Tagged Packets Use PVID
4: Ingress Security Low 19: Ingress Security Low
5: Egress Policy Pass 20: Egress Policy Pass
Port 2 6: Port Priority (PRI) 0 Mngmnt 21: Port Priority (PRI) 0
7: PVID (Port VLAN ID) 2 22: PVID (Port VLAN ID) 2
8: Tagged Packets Use PVID 23: Tagged Packets Use PVID
9: Ingress Security Low 24: Ingress Security Low
10: Egress Policy Pass 25: Egress Policy Pass
BP A 11: Port Priority (PRI) 0
12: PVID (Port VLAN ID) 2
13: Tagged Packets Use PVID
14: Ingress Security Low
15: Egress Policy Pass
Enter Choice, Previous Screen(0), (H)elp, E(x)it >
SA
Tag VLAN Control - iConverter 2FXM iConverter, Serial Agent
Identifier -
Chassis Number = 1 Slot Number = 1 Model Number = 8959-0
Port 1 1: Port Priority (PRI) 0
2: PVID (Port VLAN ID) 2
3: Tagged Packets Use PVID
4: Ingress Security Low
5: Egress Policy Pass
Port 2 6: Port Priority (PRI) 0
7: PVID (Port VLAN ID) 2
8: Tagged Packets Use PVID
9: Ingress Security Low
10: Egress Policy Pass
Mngmnt 11: Port Priority (PRI) 0
12: PVID (Port VLAN ID) 2
13: Tagged Packets Use PVID
14: Ingress Security Low
15: Egress Policy Pass
Enter Choice, Previous Screen(0), (H)elp, E(x)it >
Page 38
