3.5
VERIFY OPERATION
PI
SA
Once the module has been installed and configured, per Sections 3.2 - 3.4, verify the module is operational
by viewing the status of the LED indicators. The table below provides a description for each LED indicator.
The Power LED indicates the module is receiving power from the chassis or power cord. The plug-in
modules has an LED indicator for each available power supply in the chassis (the 19-Module Chassis has
three, the 5-Module Chassis has two).
The Fiber Optic LEDs (“P1” and “P2”) indicate the fiber optic connections have been established. A
blinking LED indicates the presence of data.
Refer to Section 6.0, Troubleshooting Guide, for help in determining possible fault conditions.
PI
SA
PI
SA
LED Function
"Legend"
Color
Off State
On / Blinking State
On / Blinking State
Power "Pwr"
Amber No power
On: Module has power
On: Module has power
Power Supply Status
#X
Amber
Chassis Power
Supply not installed
On: Power available from
installed Power Supply #X
Blinking: No power available
from installed Power Supply #X
Not available on standalone
Port 1
Fiber Link Activity
"P1"
Green No Fiber Link
On: Fiber link is active
Blinking: Receiving Fiber Data
On: Fiber link is active
Blinking: Receiving Fiber Data
Port 1
Half/Full Duplex
"FDX"
Green Half-Duplex
On: Full-Duplex
On: Full-Duplex
Chassis Management
Master/Slave
"Msr/Slv"
Green
Chassis Slave
Mode
On: Chassis Master
Blinking: Operating in OAM
Mode
Not available on standalone
Port 2
Fiber Link Activity
"P2"
Green No Fiber Link
On: Fiber link is active
Blinking: Receiving Fiber Data
On: Fiber link is active
Blinking: Receiving Fiber Data
Port 2
Half/Full Duplex
"FDX"
Green Half-Duplex
On: Full-Duplex
On: Full-Duplex
