Page 36
PI
Module - iConverter 2FXM iConverter, Serial Agent
Identifier -
Chassis Number
= 1
Port VLAN Path Setup
Slot Number
= 11 ----------------------------------
Model Number
= 8959-0
11: Port 1 to Port 2
Enable
On
12: Port 1 to BP A
Enable
On
Port Access Control Setup
13: Port 1 to BP B
Enable
On
----------------------------------
14: Port 2 to BP A
Enable
On
1: Port 1 Enable
On
15: Port 2 to BP B
Enable
On
2: Port 2 Enable
On
16: BP A to BP B
Enable
On
17: Port 1 to Mngmnt
Enable
On
Enhanced Features
18: Port 2 to Mngmnt
Enable
On
----------------------------------
19: BP A to Mngmnt
Enable
On
3: 802.1Q Processing Enable
Off
20: BP B to Mngmnt
Enable
On
4: Configure Tag VLAN Control
5: Configure VLAN Membership
Bandwidth Control
6: Save TAG VLAN parameters --------------------------------
7: Configure 802.3ah parameters
21: Ingress rate Port 1
No Limit
8: Configure 802.3ah events
22: Egress rate Port 1
No Limit
9: SFP Information
23: Ingress rate Port 2
No Limit
10: cNode Loopback
24: Egress rate Port 2
No Limit
Enter Choice, Previous Screen(0), (H)elp, E(x)it >
SA
Module - iConverter 2FXM iConverter, Serial Agent
Identifier -
Chassis Number
= 1
Port VLAN Path Setup
Slot Number
= 11 ----------------------------------
Model Number
= 8959-0
11: Port1 to Port2
Enable
On
12: Port1 to Mngmnt Enable
On
Port Access Control Setup
13: Port2 to Mngmnt Enable
On
----------------------------------
1: Port 1 Enable
On
Bandwidth Control
2: Port 2 Enable
On
--------------------------------
14: Ingress rate Port 1 No Limit
Enhanced Features
15: Egress rate Port 1 No Limit
----------------------------------
16: Ingress rate Port 2 No Limit
3: 802.1Q Processing Enable
Off
17: Egress rate Port 2 No Limit
4: Configure Tag VLAN Control
5: Configure VLAN Membership
6: Save TAG VLAN parameters
7: Configure 802.3ah parameters
8: Configure 802.3ah events
9: SFP Information
10: cNode Loopback
Enter Choice, Previous Screen(0), (H)elp, E(x)it >
