Description Item
Assign an array to the selected trace that is added on the Y axis. Click the
drop-down button for a list of available resource arrays. When a second trace
is added to a Y axis, the signal list is filtered to only show arrays. Y Array
Clear the check box to use the index of the array for the X axis. X Array
Select the box, click the drop-down button, and select an array to plot on the
X axis.
Shows vertical and horizontal guidelines that move with the cursor. Highlight
a point on the graph to show its X and Y values. Point Pick
Edit the size, color, location, and border of the charts title and legend. Titles and Legend
5.2.4.0 X-Axis and Y-Axis Properties
X-Axis and Y-Axis Properties
Description Item
Select a display unit for the selected trace signal. The list only shows the set
of units that are compatible with the dimension of the signal that is assigned
to the selected trace. Display Unit
Blank is the default value.
Set the display range of the Y axis to the maximum or minimum values. Maximum or Minimum
Click the corresponding button to use this feature.
To have the software calculate the maximum or minimum value(s) of the Y
signal and then set the maximum or minimum display range to the value(s),
click to clear the required check boxes.
To manually set the maximum or minimum display range for the Y axis, select
the required check boxes and then specify the maximum or minimum values.
Set the display range of the Y axis to the amplitude or mean values. Amplitude
is a plus or minus display range. Mean is an offset, and the amplitude is relative
to the mean. Mean or Amplitude
• Click the corresponding button to use this feature.
• Click to clear the check box(es) to have the application set the amplitude
or mean display range to the amplitude or mean value(s) of the X signal.
• Select the check box(es) and then specify the amplitude or mean values
to manually set the amplitude or mean display range for the X axis.
Toggle between linear scale and log scale for the axis. Select the check box
for logarithmic scale. Leave the box blank for linear scale. Log Scale
