Accessory Mounting Dimensions
Installation
Accessory Mounting Dimensions
You can attach numerous testing accessories and fixtures to the load frame for
specialized tests. The following figures show the standard mounting holes in
each style of load frame. Use these standard mounting holes to mount your
accessories. Avoid tapping new holes that may weaken or otherwise compromise
the integrity of the load frame. The following sections describe each style of load
frame separately. Look for the section pertaining to your specific model for the
appropriate dimensions.
Note
All measurements in the following figures are shown in mm.
