MTS Criterion ® Series 40 Product Manual 38
Specifications
Introduction
Specifications of Model C42
P ARAMETER S PECIFICATION
M ODEL C42.503
Maximum rated force capacity 5 kN (1100 lbf )
Force capacity options 1 N, 5 N, 10 N, 25 N, 50 N, 100 N, 250 N, 500 N
1 kN, 2 kN, 5 kN
(0.2 lbf, 1 lbf, 2 lbf, 5 lbf, 10 lbf, 20 lbf, 50 lbf, 110 lbf
220 lbf, 450 lbf, 1100 lbf)
Frame type 1 Guide column, table-top
Test zone Single
Maximum test speed 2000 mm/min (78.7 in/min)
Minimum test speed 0.005 mm/min (0.0002 in/min)
Position resolution 0.00005 mm (0.000002 in)
Vertical test space
Standard length
Extended length
820 mm (32.3 in)
1120 mm (44.1 in)
Crosshead travel
Standard length
Extended length
650 mm (25.6 in)
950 mm (37.4 in)
Clearance from loading axis to column cover 100 mm (3.94 in)
Frame height
Standard length
Extended length
1332 mm (52.44 in)
1632 mm (64.25 in)
Frame width 704 mm (27.7 in)
Frame depth 636 mm (25 in)
Weight
Standard length with enclosure
Standard length without enclosure
Extended length with enclosure
Extended length without enclosure
142 kg (312 lb)
112 kg (246 lb)
161 kg (354.2 lb)
125 kg (275 lb)
Power requirements 200-230 V AC
5 Amp
50/60 Hz
1000 W
1 Phase
