Page 77
Installing Cables
MTS Criterion
®
Series 40 Product Manual
Installation
77
J13 Digital I/O User
Digital I/O signals include three optically isolated inputs, three optically isolated
outputs, and 12 V power. Functions of each digital input or output are software
selectable. A typical example might be connecting an external switch; see
“Additional Digital I/O Information”
on page 125. Only DIN1 and DOUT2 & 3
are available for external use. DIN2 & DOUT1 are used for Fault Status
communications with the software. DIN3 is used for Enclosure door switch
status. Pin assignments are as follows:
Note
If the optional enclosure is not used, DIN3 is still required by the control
system to bypass the low-speed safety system.
P
IN
S
IGNAL
1
DIN1+
2
DIN2+
3
DIN3+
4
DOUT1+
5
DOUT2+
6
DOUT3+
7
No Contact
8
VCC
9
DIN1-
10
DIN2-
11
DIN3-
12
DOUT1-
13
DOUT2-
14
DOUT3-
15
Analog GND
Criterion_product manual.book Page 77 Monday, July 28, 2014 3:52 PM
