MTS Criterion ® Series 40 Product Manual 36
Specifications
Introduction
Common Specifications
The following specifications are for all MTS Criterion frames. Specifications for
the specific models are located in the following tables.
C ALIBRATION S TANDARD ISO 7500 C LASS 0.5 OR ASTM E4 ISO 7500 C LASS 1
Force range 1-100% of rated force capacity 0.5-1% of force rated
capacity
Rated force capacity at max test speed 100%
Maximum test speed at rated force
capacity 100%
Force indicating accuracy ± 0.5 % of indicating
Speed accuracy Set speed < 0.01 mm/min: speed accuracy is within ± 1.0% of set
speed
Set speed ≥ 0.01 mm/min: speed accuracy is within ± 0.2% of set
speed
Position accuracy Within ± 0.5%
Strain accuracy ASTM E83 or ISO 8513
Security protection Over-Force, travel limits, over-voltage and others
Over force protection 10%
Data acquisition rate 1000 Hz
Control loop rate 1000 Hz
Environmental requirements
Operating temperature
Operating humidity
Storage temperature
Maximum storage humidity
Maximum altitude
For indoor use only
5-40°C (41-104°F)
5-85% Noncondensing
-18-49°C (0-120°F)
90% Noncondensing
2000 m (6562 ft)
Motor and
drive system AC Servomotor
Ball
screws Preloaded
Position measurement Encoder
Additional DC conditioning channels 2 channels
Additional incremental encoder
conditioning channels 1 channel
