MTS Criterion ® Series 40 Product Manual 42
Specifications
Introduction
Specifications of Model C45 (part 1 of 2)
P ARAMETER S PECIFICATION
M ODEL C45.504 C45.504W C45.105
Maximum rated force capacity 50 kN 50 kN 100 kN
Force capacity options 1 kN, 2.5 kN, 5 kN, 10
kN, 20 kN, 30 kN, 50
kN 1 kN, 2.5 kN, 5 kN, 10
kN, 20 kN, 30 kN, 50
kN 1 kN, 2.5 kN, 5 kN, 10
kN, 20 kN, 30 kN, 50
kN,100 kN
(220 lbf, 500 lbf, 1100
lbf, 2200 lbf, 4400 lbf,
6600 lbf, 11000 lbf) (220 lbf, 500 lbf, 1100
lbf, 2200 lbf, 4400 lbf,
6600 lbf, 11000 lbf) (220 lbf, 500 lbf, 1100
lbf, 2200 lbf, 4400 lbf,
6600 lbf, 11000 lbf,
22000 lbf)
Frame type 2 Guide columns
Floor-standing 2 Guide columns
Floor-standing 2 Guide columns
Floor-standing
Test zone Single or Dual Single Single or Dual
Maximum test speed 750 mm/min
(29.53 in/min) 750 mm/min
(29.53 in/min) 750 mm/min
(29.53 in/min)
Minimum test speed 0.005 mm/min
(0.0002 in/min) 0.005 mm/min
(0.0002 in/min) 0.005 mm/min
(0.0002 in/min)
Position resolution 0.000047 mm
(0.0000019 in) 0.000047 mm
(0.0000019 in) 0.000047 mm
(0.0000019 in)
Vertical test space
Standard length
Extended length
1220 mm (48.0 in)
1520 mm (59.8 in)
1520 mm (59.8 in) 1220 mm (48.0 in)
1520 mm (59.8 in)
Crosshead travel
Standard length
Extended length
1000 mm (39.37 in)
1300 mm (51.18 in)
1300 mm (51.18 in) 1000 mm (39.37 in)
1300 mm (51.18 in)
Space between columns 600 mm (23.62 in) 1000 mm (39.37 in) 600 mm (23.62 in)
Frame height
Standard length
Extended length
2269 mm (89.3 in)
2569 mm (101.1 in)
2569 mm (101.1 in) 2269 mm (89.3 in)
2569 mm (101.1 in)
Frame width 1315 mm (51.77 in) 1710 mm (67.32 in) 1315 mm (51.77 in)
Frame depth 957 mm (37.68 in) 957 mm (37.68 in) 957 mm (37.68 in)
