Page 65
Dual-Column Load Frames
MTS Criterion
®
Series 40 Product Manual
Installation
65
Front of dual-column
units
A typical installation procedure for installing the front enclosure for dual-column
units is provided following the figure.
I
TEM
D
ESCRIPTION
1
Left Side Panel Assembly
2
M6 Butt Fastener
3
M6 X20 mm Socket Head Screw
4
Horizontal bar
5
M4X35 mm Crossed Discal Screws
6
Safety Switch
7
M6X25 mm Socket Head screw
8
Safety Switch Mount Plate
9
Right Side Panel Assembly
10
M6 X40 mm Socket Head Screw
11
Front Door
1
2
3
4
5
6
7
8
9
11
10
Front of Dual-Column Load Frame
Criterion_product manual.book Page 65 Monday, July 28, 2014 3:52 PM
