Page 59: Single-column load frame 59
Installing Optional Enclosures
MTS Criterion
®
Series 40 Product Manual
Installation
59
Installing Optional Enclosures
Every MTS Criterion Series 40 Material Test System has an optional test area
enclosure. If the MTS test enclosure is not purchased, customers must provide an
enclosure of their own to protect against ejected parts or materials from test
specimens.
Single-Column Load Frame
The optional enclosure for single-column load frames is comprised of a back
frame and a front door, which completely encloses the test space.
When shipping, front door and back frame of enclosure are removed from the
frame and packaged separately. After the frame is placed in its testing location,
you need to install enclosure.
C41 model
A typical installation procedure for installing an enclosure for C41 single-column
units is provided following the figure.
1
4
2
3
6
8
5
7
10
9
11
12
13
Criterion_product manual.book Page 59 Monday, July 28, 2014 3:52 PM
