Function library "LenzeIo1000Drv"
Function blocks
L_io1000Data610 - process data transfer PDO6 ... PDO10
Inputs
Outputs
Identifier/data type
Information/possible settings
bEnablePDOTransfer
BOOL
TRUE Start process data communication
abyPDO6...10_DataToIO
ARRAY[1..8] OF BYTE
Process data to be sent (PLC I/O system)
bResetFail
BOOL
TRUE Reset outputs bFail_DataToIO, bFail_DataFromIO and bFail_Module
to FALSE
DataFrom_IOParPDO610
io1000_ParPDO610
Communication-relevant parameters for the process data objects PDO6 ... PDO10
• Input for accepting the structure data of
parameterisation
block.
DataFrom_IParComGuarding
io1000_
ParTimeOutPDO610
Monitoring times for the process data objects PDO6 ... PDO10
• Input for accepting the structure data DataTo_IOData610 from the
parameterisation block
Identifier/data type
Value/meaning
dnState
DINT
Status
2 Waiting for completing the parameter setting through the
FB
1 Initialisation ok, ready for data exchange.
-1000 Error in NMT command "start node"
dnStatePDO6...10
_DataToIO
DINT
Transmission status PDO6 ... PDO10 (PLC I/O system)
0 No error
3 PDO has been deactivated
2 Process data communication is not active
-150 CAN interface of the PLC is not in the "Operational" status
-160 Error while reading out the status of the CAN interface
-1000 Error while sending process data
-1002 Wrong handling has been transmitted to internal transmit block
-1003 Wrong data length has been transmitted to the internal transmit
block
-1004 Wrong identifier has been transmitted to internal transmit block
-1007 Wrong transmission mode has been transmitted to internal
transmit block
-1100 Output buffer is full
