Function library "LenzeIo1000Drv"
Function blocks
L_io1000ParCounterEPMS601 - Parameterise counter
4.5 L_io1000ParCounterEPMS601 - Parameterise counter
This FB serves to parameterise the EPM-S601 counter module.
 A FALSE/TRUE edge at the bExecute input starts the parameter setting.
 The dnState output shows the transmission status.
Call possible in: ; Cyclic task
Interrupt task
; Time-controlled task (INTERVAL)
Event-controlled task (EVENT)
L_io1000ParCounterEPMS601
⎯ bExecute bDone ⎯
⎯ dwHandle dnState ⎯
⎯ byNodeAdr
⎯ byAnalogModuleNo
⎯ bDiagnosticAlarm
⎯ byCnt0InputFrequencyTrackA
⎯ byCnt0InputFrequencyTrackB
⎯ byCnt0AlarmFunction
⎯ byCnt0CounterFunction
⎯ byCnt0SignalSelection
⎯ bCnt0InternalGateInterrupt
⎯ byCnt0CompareFunction
⎯ bCnt0InvertDirectionTrackB
⎯ dwCnt0SetValue
⎯ dwCnt0LoadValue
⎯ dwCnt0EndValue
⎯ byCnt0Hysteresis
⎯ byCnt1InputFrequencyTrackA
⎯ byCnt1InputFrequencyTrackB
⎯ byCnt1AlarmFunction
⎯ byCnt1CounterFunction
⎯ byCnt1SignalSelection
⎯ bCnt1InternalGateInterrupt
⎯ byCnt1CompareFunction
⎯ bCnt1InvertDirectionTrackB
⎯ dwCnt1SetValue
⎯ dwCnt1LoadValue
⎯ dwCnt1EndValue
⎯ byCnt1Hysteresis
