L_io1000ParCounterEPMS604 - Parameterise encoder evaluation
4.8 L_io1000ParCounterEPMS604 - Parameterise encoder evaluation
This FB serves to parameterise the I/O compound module EPM-S604. The module is an SSI
interface for direct connection to an SSI encoder.
 A FALSE/TRUE edge at the bExecute input starts the parameter setting.
 The dnState output shows the transmission status.
Inputs
Call possible in: ; Cyclic task
Interrupt task
; Time-controlled task (INTERVAL)
Event-controlled task (EVENT)
L_io1000ParCounterEPMS604
⎯ bExecute bDone ⎯
⎯ dwHandle dnState ⎯
⎯ byNodeAdr
⎯ byAnalogModuleNo
⎯ bDiagnosticAlarm
⎯ byDeadTime
⎯ byBaudrate
⎯ dwScaling
⎯ byBitLength
⎯ bMasterMode
⎯ bMsbFirst
⎯ bRisingEdgeSignal
⎯ bGrayCode
⎯ bSSIFunctionEnabled
Identifier/data type Information/possible settings
bExecute
BOOL
FALSEÊTRUE Start parameter setting of the analog output module
dwHandle
DWORD
• 9400 ServoPLC: Handle created by FB L_CanInit
• Drive PLC, 9300 Servo PLC, ECS: 10
byNodeAdr
BYTE
1 ... 127 CAN node address of the I/O system
byAnalogModuleNo
BYTE
1 ... 64 Number of the analog output module
bDiagnosticAlarm
BOOL
TRUE Enable diagnostic alarm
