Function library "LenzeIo1000Drv"
Function blocks
L_io1000ParAiTemperature - Parameterise temperature measurement
14
L
DMS 1.0 EN - 07/2011 - TD05
4.2 L_io1000ParAiTemperature - Parameterise temperature measurement
This FB serves to parameterise the analog input modules EPM-S404 and EPM-S405.
 A FALSE/TRUE edge at the bExecute input starts the parameter setting.
 The dnState output shows the transmission status.
Call possible in: ; Cyclic task
Interrupt task
; Time-controlled task (INTERVAL)
Event-controlled task (EVENT)
L_io1000ParAiTemperature
⎯ bExecute bDone ⎯
⎯ dwHandle dnState ⎯
⎯ byNodeAdr
⎯ byAnalogModuleNo
⎯ byNoOfChannels
⎯ bDiagnosticAlarm
⎯ byTemperatureSystem
⎯ byFilter
⎯ bWireBreakDetection_CH1
⎯ byFunction_CH1
⎯ bySampling_CH1
⎯ bLimitAlarm_CH1
⎯ nUpperLimit_CH1
⎯ nLowerLimit_CH1
⎯ bWireBreakDetection_CH2
⎯ byFunction_CH2
⎯ bySampling_CH2
⎯ bLimitAlarm_CH2
⎯ nUpperLimit_CH2
⎯ nLowerLimit_CH2
⎯ bWireBreakDetection_CH3
⎯ byFunction_CH3
⎯ bySampling_CH3
⎯ bLimitAlarm_CH3
⎯ nUpperLimit_CH3
⎯ nLowerLimit_CH3
⎯ bWireBreakDetection_CH4
⎯ byFunction_CH4
⎯ bySampling_CH4
⎯ bLimitAlarm_CH4
⎯ nUpperLimit_CH4
⎯ nLowerLimit_CH4
