Function library "LenzeIo1000Drv"
Function blocks
L_io1000ParAiTemperature - Parameterise temperature measurement
Inputs
Identifier/data type Information/possible settings
bExecute
BOOL
FALSEÊTRUE Start parameter setting of the analog input module
dwHandle
DWORD
• 9400 ServoPLC: Handle created by FB L_CanInit
• Drive PLC, 9300 Servo PLC, ECS: 10
byNodeAdr
BYTE
1 ... 127 CAN node address of the I/O system
byAnalogModuleNo
BYTE
1 ... 64 Number of the analog input module
byNoOfChannels
BYTE
Number of channels of the I/O system
2 EPM-S405
4 EPM-S404
bDiagnosticAlarm
BOOL
TRUE Enable diagnostic alarm
byTemperatureSystem
BYTE
Temperature system
0 °C
1 °F
2 K
byFilter
BYTE
Activate interference frequency suppression
1 60 Hz
2 50 Hz
bWireBreakDetection
_CH1 ... _CH4
BOOL
TRUE Activate open circuit detection channel 1 ... 4
byFunction_CH1 ... _CH4
BYTE
Function channel 1 ... 4
• see system manual "I/O system 1000":
EPM-S404: Chapter 7.9.1
EPM-S405: Chapter 7.9.2
bySampling_CH1 ... _CH4
BYTE
Conversion time channel 1 ... 4
• see system manual "I/O system 1000":
EPM-S404: Chapter 7.9.1
EPM-S405: Chapter 7.9.2
bLimitAlarm_CH1 ... _CH4
BOOL
TRUE Activate limit value monitoring channel 1 ... 4
nUpperLimit_CH1 ... _CH4
BYTE
Upper limit value channel 1 ... 4
nLowerLimit_CH1 ... _CH4
BYTE
Lower limit value channel 1 ... 4
