Function library "LenzeIo1000Drv"
Function blocks
L_io1000ParAiDc - Parameterise analog inputs
12
L
DMS 1.0 EN - 07/2011 - TD05
4.1
L_io1000ParAiDc - Parameterise analog inputs
This FB serves to parameterise the analog input modules EPM-S400, EPM-S401, EPM-S402
and EPM-S403.
A FALSE/TRUE edge at the bExecute input starts the parameter setting.
The dnState output shows the transmission status.
Inputs
Call possible in:
;
Cyclic task
Interrupt task
;
Time-controlled task (INTERVAL)
Event-controlled task (EVENT)
L_io1000ParAiDc
⎯ bExecute
bDone ⎯
⎯ dwHandle
dnState ⎯
⎯ byNodeAdr
⎯ byAnalogModuleNo
⎯ byNoOfChannels
⎯ byFunction_CH1
⎯ byFunction_CH2
⎯ byFunction_CH3
⎯ byFunction_CH4
Identifier/data type
Information/possible settings
bExecute
BOOL
FALSEÊTRUE Start parameter setting of the analog input module
dwHandle
DWORD
• 9400 ServoPLC: Handle created by FB L_CanInit
• Drive PLC, 9300 Servo PLC, ECS: 10
byNodeAdr
BYTE
1 ... 127 CAN node address of the I/O system
byAnalogModuleNo
BYTE
1 ... 64 Number of the analog input module
byNoOfChannels
BYTE
Number of channels of the I/O system
2 EPM-S400, EPM-S402
4 EPM-S401, EPM-S403
byFunction_CH1 ... _CH4
BYTE
Function channel 1 ... 4
• see system manual "I/O system 1000":
EPM-S400: Chapter 7.8.1
EPM-S401: Chapter 7.8.2
EPM-S402: Chapter 7.8.3
EPM-S403: Chapter 7.8.4
