Function library "lenzeio1000drv – Lenze Function library LenzeIO1000Drv User Manual
Page 33

DMS 1.0 EN - 07/2011 - TD05
L
33
Function library "LenzeIo1000Drv"
Function blocks
L_io1000ParCounterEPMS603 - Parameterise counter
byCnt0
InputFrequencyTrackB
BYTE
Counter 1: Input filter of digital input 5, "B1"/"direction"
2 100 kHz
3 60 kHz
4 30 kHz
6 10 kHz
7 5 kHz
8 2 kHz
9 1 kHz
byCnt0SignalSelection
BYTE
Counter 1: Signal evaluation
0 Counter deactivated
• The other parameter data for the counter are ignored.
1 Rotary transducer 1-fold (at A and B)
2 Rotary transducer 2-fold (at A and B)
3 Rotary transducer 4-fold (at A and B)
4 Direction (pulse at A and direction at B)
bCnt0InvertDirectionTrackB
BOOL
TRUE Counter 1: Invert counting direction track B
byCnt1
InputFrequencyTrackA
BYTE
Counter 2: Input filter of digital input 4, "A2"/"pulse"
2 100 kHz
3 60 kHz
4 30 kHz
6 10 kHz
7 5 kHz
8 2 kHz
9 1 kHz
byCnt1
InputFrequencyTrackB
BYTE
Counter 1: Input filter of digital input 8, "B2"/"direction"
2 100 kHz
3 60 kHz
4 30 kHz
6 10 kHz
7 5 kHz
8 2 kHz
9 1 kHz
byCnt1SignalSelection
BYTE
Counter 2: Signal evaluation
0 Counter deactivated
• The other parameter data for the counter are ignored.
1 Rotary transducer 1-fold (at A and B)
2 Rotary transducer 2-fold (at A and B)
3 Rotary transducer 4-fold (at A and B)
4 Direction (pulse at A and direction at B)
bCnt1InvertDirectionTrackB
BOOL
TRUE Counter 2: Invert counting direction track B
Identifier/data type
Information/possible settings
