Function library "LenzeIo1000Drv"
Function blocks
L_io1000Data610 - process data transfer PDO6 ... PDO10
58
L
DMS 1.0 EN - 07/2011 - TD05
4.14 L_io1000Data610 - process data transfer PDO6 ... PDO10
This FB coordinates the digital and analog input/output data of the process data objects
PDO6 ... PDO10. The FB is the interface between the PLC and the I/O system.
 Data from the PLC are transmitted to the I/O system (digital and analog output
channels) via the abyPDO6...10_DataToIO inputs.
 The statuses of the digital and analog input channels are transmitted to the PLC via the
abyPDO6...10_DataFromIO outputs.
Call possible in: ; Cyclic task
Interrupt task
; Time-controlled task (INTERVAL)
Event-controlled task (EVENT)
L_io1000Data610
⎯ bEnablePDOTransfer dnState ⎯
⎯ abyPDO6_DataToIO dnStatePDO6_DataToIO ⎯
⎯ abyPDO7_DataToIO dnStatePDO7_DataToIO ⎯
⎯ abyPDO8_DataToIO dnStatePDO8_DataToIO ⎯
⎯ abyPDO9_DataToIO dnStatePDO9_DataToIO ⎯
⎯ abyPDO10_DataToIO dnStatePDO10_DataToIO ⎯
⎯ bResetFail dnStatePDO6_DataFromIO ⎯
⎯ DataFrom_IOParPDO610 dnStatePDO7_DataFromIO ⎯
⎯ DataFrom_IParComGuarding dnStatePDO8_DataFromIO ⎯
dnStatePDO9_DataFromIO ⎯
dnStatePDO10_DataFromIO ⎯
bFail_DataToIO ⎯
bFail_DataFromIO ⎯
bFail_Module ⎯
abyPDO6_DataFromIO ⎯
abyPDO7_DataFromIO ⎯
abyPDO8_DataFromIO ⎯
abyPDO9_DataFromIO ⎯
abyPDO10_DataFromIO ⎯
