Function library "LenzeIo1000Drv"
Function blocks
L_io1000ParCounterEPMS603 - Parameterise counter
32
L
DMS 1.0 EN - 07/2011 - TD05
4.7 L_io1000ParCounterEPMS603 - Parameterise counter
This FB serves to parameterise the EPM-S603 counter module.
 A FALSE/TRUE edge at the bExecute input starts the parameter setting.
 The dnState output shows the transmission status.
Inputs
Call possible in: ; Cyclic task
Interrupt task
; Time-controlled task (INTERVAL)
Event-controlled task (EVENT)
L_io1000ParCounterEPMS603
⎯ bExecute bDone ⎯
⎯ dwHandle dnState ⎯
⎯ byNodeAdr
⎯ byAnalogModuleNo
⎯ byCnt0InputFrequencyTrackA
⎯ byCnt0InputFrequencyTrackB
⎯ byCnt0SignalSelection
⎯ bCnt0InvertDirectionTrackB
⎯ byCnt1InputFrequencyTrackA
⎯ byCnt1InputFrequencyTrackB
⎯ byCnt1SignalSelection
⎯ bCnt1InvertDirectionTrackB
Identifier/data type Information/possible settings
bExecute
BOOL
FALSEÊTRUE Start parameter setting of the analog output module
dwHandle
DWORD
• 9400 ServoPLC: Handle created by FB L_CanInit
• Drive PLC, 9300 Servo PLC, ECS: 10
byNodeAdr
BYTE
1 ... 127 CAN node address of the I/O system
byAnalogModuleNo
BYTE
1 ... 64 Number of the analog output module
byCnt0
InputFrequencyTrackA
BYTE
Counter 1: Input filter of digital input 1, "A1"/"pulse"
2 100 kHz
3 60 kHz
4 30 kHz
6 10 kHz
7 5 kHz
8 2 kHz
9 1 kHz
