Lenze Function library LenzeIO1000Drv - Manual (Page 29)

DMS 1.0 EN - 07/2011 - TD05
L
29
Function library "LenzeIo1000Drv"
Function blocks
L_io1000ParCounterEPMS602 - Parameterise counter
byInputFrequencyTrackA
BYTE
Input filter of digital input 1 and 5, "A"/"pulse"
2 100 kHz
3 60 kHz
4 30 kHz
6 10 kHz
7 5 kHz
8 2 kHz
9 1 kHz
byInputFrequencyTrackB
BYTE
Input filter of digital input 4 and 8, "B"/"direction"
2 100 kHz
3 60 kHz
4 30 kHz
6 10 kHz
7 5 kHz
8 2 kHz
9 1 kHz
byInputFrequencyReset
BYTE
Input filter of digital input 6 and 7, "reset"
2 100 kHz
3 60 kHz
4 30 kHz
6 10 kHz
7 5 kHz
8 2 kHz
9 1 kHz
byAlarmFunction
BYTE
Process alarm
A process alarm can be triggered in case of the following events:
bits0 Reserved
bits1 Reserved
Bit 2 Counter limit overflow
bits3 Counter limit underflow
bits4 Comparison value reached
Bit 5 Final value reached
Bit 6 Reserved
Bit 7 Reserved
byCounterFunction
BYTE
Counting function
0 Continuous counting
1 Single counting, main counting direction is forward
2 Single counting, main counting direction is backward
3 Single counting, no main counting direction
4 Periodic counting, main counting direction is forward
5 Periodic counting, main counting direction is backward
6 Periodic counting, no main counting direction
Identifier/data type Information/possible settings
