Function library "LenzeIo1000Drv"
Function blocks
L_io1000ParCounterEPMS604 - Parameterise encoder evaluation
36
L
DMS 1.0 EN - 07/2011 - TD05
byDeadTime
BYTE
TimeOut
1 1 μs
2 2 μs
3 4 μs
4 8 μs
5 16 μs
6 32 μs
7 48 μs
8 64 μs
byBaudrate
BYTE
Baud rate
1 2000 kHz
2 1500 kHz
3 1000 kHz
4 500 kHz
5 250 kHz
6 125 kHz
dwScaling
DWORD
Scaling
byBitLength
BYTE
Bit length
bMasterMode
BOOL
FALSE Listen-in operation
TRUE Master operation
bMsbFirst
BOOL
FALSE LSB is transmitted first
TRUE MSB is transmitted first
bRisingEdgeSignal
BOOL
FALSE Falling edge
TRUE Rising edge
bGrayCode
BOOL
FALSE Standard code
TRUE Gray code
bSSIFunctionEnabled
BOOL
TRUE SSI function enabled
Identifier/data type Information/possible settings
