9400 Technology applications | Electronic gearbox
Parameter setting & configuration
Parameterisable function blocks
78
L
EDS94TA10030xxxx EN 1.2 - 11/2009
5.16.12
VirtualMaster
Is an instance of
Function
L_LdVirtualMaster
"Virtual master"
Master value source: Virtual master ( 42)
Parameter
Possible settings
Information
C03565
Virtual master operating mode
0 Continuous operation
Lenze setting
1 Inching
2 Handwheel function
C03566
Character string
Speed unit
• Read only
C03567
-214748.3647
unit/t
214748.3647 Reference speed
• Read only
• Reference value for selecting
speeds.
C03568/1
-214000.0000
unit/t
214000.0000 Master speed 1
• Initialisation: 1.0000 units/t
C03568/2
-214000.0000
unit/t
214000.0000 Master speed 2
• Initialisation: 1.0000 units/t
C03569/1
0.0000
unit/t
214000.0000 Manual speed CW rotation
• Initialisation: 1.0000 units/t
C03569/2
0.0000
unit/t
214000.0000 Manual speed CCW rotation
• Initialisation: 1.0000 units/t
C03570/1
0.010
s
130.000 Ramp for manual jog
• Initialisation: 1.000 s
C03570/2
0.010
s
130.000 Ramp for continuous operation/
single cycle
• Initialisation: 1.000 s
C03570/3
0.010
s
130.000 Stop ramp
• Initialisation: 1.000 s
C03579
-2147483647
2147483647 State
• Display of the bit-coded output
signal dnState.
C03582
-214748.3647
unit
214748.3647 Speed at the output
• Read only
• Is generated from the speed
signal dnSpeedOut_s.
C03583
-214748.3647
unit
214748.3647 External master speed at the input
• Read only
• Is generated from the speed
signal dnExtMaster_s.
