9400 Technology applications | Electronic gearbox
Short setup
20
L
EDS94TA10030xxxx EN 1.2 - 11/2009
4 Short setup

Note!
The electrical shaft can be implemented with a bus system as e.g. system bus
(CAN) or Ethernet Powerlink or via digital frequency transmission.
With regard to the configuration of the digital frequency extension module in
the controller, two variants of technology applications are available in the
»Engineer« application catalog.
• In the TA variant "Electronic gearbox" the configuration of a digital frequency
extension module is expected. Therefore, the TA can provide the function of
the electrical shaft either via digital frequency transmission and via a bus
system.
• In the TA variant "Electronic gearbox MotionBus" the configuration of a digital
frequency extension module is not included and corresponding interfaces are
not available in the TA. Thus the function of the electrical shaft with this TA
can only be provided via a bus system.
