4.1.1 Software structure For operation with the control unit the user interface is divided into 2 levels.
Level 1 contains the main menu.
Level 2 is used to select the parameters required.
Mainmenu Parameter
01 DIPSPLAY Output frequency
Speed
Motor current
...............
02 APPLICATION Speed limit
PAR. Ref.overspeed
Ramp up
...............
03 CONFIGURATION Reaktion OFF
Auto Testart Time
RS422: Baudrate
...............
04 ANALOG I/O’s Main demand 27/28
Add. demand 29/30
A-output 1:33
A-output 2:35
................
05 DIGITAL I/O’s D-Input 1:14
D-Input 2:15
D-Input 3:16
D-Output 1:23/24
................
06 RATINGS Motor-type
Nom. motor power
Nom. motor voltage
.................
07 CONTROL Control structure
Speed cntrl. Kp
..................
08 DIAGNOSTICS First Fault
Event Nr.
..................
09 PASSWORD Protection Level
Password Level 1
Password Level 2
................
10 LANGUAGE SEL. Language
All options on the main menu are listed with the relevant codes on a label on the back
of the control unit.
See section 4.3 for the full menu.
