Operation and Software
BA8230 95
4.3 Menu
01 DISPLAY Output frequency 50.0 Hz
Speed 1460.0 1/min
1)
Motor current 34.5 A
Motor voltage 400.0 V
Torque 120.0 Nm
1)
Motor power 18.5 kW
1)
DC link voltage 530.0 V
Temp. heatsink. 25 °C
Working time 49.50 h
Date, Time 01.06.95 10:30:10
Software ID 29152712
Software Version Lenze 8230 V2.0
Drive Name
02 APPLICATION PAR. Speed limit 1500 1/min
Protection Level 1 Ref. overspeed 1800 1/min
Crnt.lmt.max.mot.. 150 %
Crnt.lmt.max.gen.. 100 %
Crnt.lmt.nom.mot. 100 %
Protection Level 2
Crnt.lmt.nom.gen. 100 %
Ramp up 2.000 s
Rampe down 5.000 s
Ramp fast stop 0.200 s
Motpot ramp up 10.000 s
Motpot ramp down 10.000 s
Motpot n-max 3000 1/min
Motpot n-min 0.01 1/min
Jogging speed 30.00 1/min
Fixed speed 1 150.00 1/min
Fixed speed 2 300.00 1/min
Fixed speed 3 450.00 1/min
Fixed speed 4 600.00 1/min
Skip speed 1 750.0 1/min
Skip band 1 0.0 1/min
Skip speed 2 1500.0 1/min
Bandbreite 2 0.0 1/min
Skip speed 3 2250.0 1/min
Skip band 3 0.0 1/min
1)
No display at control structure = f-control
